RISC-V Embedded Processing Portfolio with New Motor Control ASSP Solution

Published  September 8, 2022   0
L Lakshita
Author
R9A02G020 Motor Control ASSP

Renesas Electronics Corporation has introduced the new RISC-V MCU that enables customers to benefit from a ready-to-use, turnkey solution for motor control applications, with no development cost, and is specifically optimized for advanced motor control systems. This new R9A02G020 motor control ASSP is based on RISC-V processing IP and its target applications include home/building automation, healthcare devices, home appliances, drones, and more.

The R9A02G020 RISC-V MCU ASSP hardware is specifically optimized for advanced motor control systems. Alongside ecosystem partners, this provides a complete, production-ready motor control system solution. With 32MHz performance, 48/16KB of Flash/RAM memory, and advanced analog features, the R9A02G020 provides the foundation for a turnkey motor control solution. Moreover, the availability of small package options and highest temperature support make such ASSP ideal for highly space-constrained PCB designs, within harsh environmental conditions.

Key Features of R9A02G020 RISC-V MCU ASSP

  • 32MHz 32-Bit innovative RISC-V CPU core with cost-optimized specification
  • Rich analog IP functionality incl. 3 ADC with dedicated PGA and  Sample and Hold circuit, 2 DAC on both options, 2 comparators, temperature sensor
  • Advanced motor control timers, and two watchdog timers for safety purpose
  • Small QFN packages (24 and 32-pin device)
  • High-temperature support (125 C°)
  • Support sensorless, vector control for one BLDC motor, 1/3 shunt, PFC, and Hall sensor inputs
  • 16 KB SRAM, incl. 4KB with ECC
  • Memory protection units (CPU and bus)
  • Customizable parameters & application options
  • Supported by easy-to-use PC GUIs/Configuration tools
  • Controlled by external host I/F
  • Complete reference design: hardware, software, kit, tools, hardware datasheet, software datasheet, GUI manual, app notes

The application software implementing the motor control functionality is pre-developed and programmed within the device at factory production, with specialized application code developed by IDHs (independent design houses). This enables users to add a sophisticated field-oriented motor control functionality without any effort in terms of development, testing, and validation of the implementation.
